| Slika | Naziv Model Proizvođač | Edit | Laboratorija | Kom | Godina proizvodnje | Godina nabavke Izvor sredstava Nabavna vrijednost |
Lokacija Zadužen Kontakt |
Detaljne tehničke karakteristike |
|---|---|---|---|---|---|---|---|---|
|
Microscope
ZM-1TW3-FOD-5M AMSCOPE | BIO-ICT | 1 | 2016 | 2016 2023€ | Elektrotehnički fakultet
Aćimić Ivana | Head: 360 degree rotatable 45 degree inclined trinocular • Eyepiece: 30mm super widefield high-eyepoint WH10X/22MM & WH25X/9MM • Zoom Range: 0.2X-22.5X • Diopter Adjustment: +/- 5dp • Interpupillary Distance: 2-3/16" - 2-15/16"(55-75mm) • Working Distance: 14" (350mm) • Field of View: 5-3/4" (145mm) in diameter • Stand: 12.5"x10"x0.75" (320mm x 260mm x 20mm) solid cast steel base | |
|
ELISA plate washer
APW-100 Allsheng | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 3462,90€ | Biotehnički fakultet
Latinović Nedeljko | For 96-well microplates Suitable for flat, U, V, C bottom Including 3 bottles and tubings | |
|
ELISA microplate reader
AMR-100 Allsheng | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 4510,10€ | Biotehnički fakultet
Latinović Nedeljko | Wavelength: 340 to 750 nm | |
|
CHN analyzer
628 Series Elemental Determinators Leco | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 74000€ | Biotehnički fakultet
Topalović Ana | Carbon, Hydrogen, Nitrogen determination in macro samples Instrument principle of operation – Dumas combustion method The analyzer is able to analyze from few miligrams up to minimum 0.25 g weight of samples for CHN in organic materials C: 0,02 – 175 mg H: 0,1 – 12mg N: 0,04 – 50 mg up to 1050 °C | |
|
Multi place stir/hot plate 4 place
SUPER-NUOVA MULTI POSITION THERMO SCIENTIFIC | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 2905€ | Institut za biologiju mora
Joksimović Aleksandar | Four independently controlled heating/stirring positions, ceramic top and 4-function memory | ||
|
pH Meter
PH50 XS | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 532€ | Institut za biologiju mora
Joksimović Aleksandar | pH Range: ≤ 0.00 to ≥ 14.00 Resolution: pH – 0.01 Accuracy: ± 0.01 pH + 1 LSD (two decimal digits) Temperature Compensation: Automatic/Manual (0 to 100°C) Automatic calibration 1 to 3 points | ||
|
Balance
EW2200-NM KERN | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 672€ | Institut za biologiju mora
Joksimović Aleksandar | Capacity max: 2200 g. Readability: 0.01 g. Tare facility. Digital Display Stainless Steel Weighing pan: rectangular, dimensions 180 mm x 160 mm. Automatic setting. Weighing range in grams. Precision + 0,01 g. | |
|
Code surface drifter
CODE/DAVIS ARGO DRIFTER METOCEAN | BIO-ICT | 6 | 2016 | 2016 BIO-ICT 3964€ | Institut za biologiju mora
Joksimović Aleksandar | Operation Conditions Air Temperature: -20° C to +35° C Water Temperature: -2° C to +35° C Water Type: Fresh or Salt Significant Wave Height: 8.0 m / 26 ft Wind Speed: 20 m/s / 40 knots Wind Gusts: 30 m/s / 60 knots External Humidity: 100% (external) Sunlight: Direct Exposure Operating Life: 3-12 months depending on sampling Shelf Life: 24 months with storage conditions at ~21° C Survival Conditions Air Temperature: -30° C to 35° C Water Temperature: -2° C to 35° C Significant Wave Height: 12.0 m / 40 ft Wind Speed (at 10m): 35 m/s / 70 knots Electronics Iridium Transceiver: 9602 SBD Antenna: Low Profile Dual Band Iridium/GPS Power Supply: 10 Alkaline-manganese dioxide D-cells Sensors Sea Surface Temperature: US Sensor ±.05° C Thermistor Battery Voltage: Precision Resistive Divider GPS Receiver: Jupiter F2 | |
|
Centrifuge
UNIVERSAL 320R HETTICH | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 8285€ | Institut za biologiju mora
Joksimović Aleksandar | 200-240V, 50-60Hz refrigerated bench-top centrifuge without rotor, 1 pcs Angle-rotor 6x85 ml, 1 piece – (code HT 1620A ref brochure) Reducing-part, 1-place, size 2, for tubes of 15 ml, 17x100 mm, 6 piece Reducing-part, 1-place, size 2, 6 piece for tubes of 50 ml, 34x100 mm Reducing part, 1-place, size 2, 6 piece for Falcon tubes of 15 ml, 17x120 mm, Reducing-part, 1-place, size 2, 6 piece for Falcon tubes of 50 ml, 29x115 mm Tube 15 ml, 17 x 100 mm, 15 piece cylindrical, graduated Tube 50 ml 34 x 100 mm, 15 piece cylindrical, ungraduated Tube 15 ml, conical, graduated, plastic PP, with screw cap, 500 piece Tube 50 ml, conical, graduated, plastic PP, with screw cap, 500 piece | |
|
Fume Cupboards
COMBI 1200 ASAL | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 10692€ | Institut za biologiju mora
Joksimović Aleksandar | Overall dimension w x d x h: 1280 x 780 x 1540 mm The housing sides: closed The worktops: gres monolithic The underbench cabinet: acid & base unit The exhaust air socket; the monitor/controller for air, The lighting, two-piece panel made of laminated safety glass; Cold water tap; electrical sockets; Main fan unit with 5 mm PVC pipes | |
|
Milli-Q Water Purification System
MILLI-Q Reference MERCK/MILLIPORE | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 9077€ | Institut za biologiju mora
Joksimović Aleksandar | Resistivity 18.2 MΩ.cm at 25 °C TOC ≤ 5 ppb (μg/L) Bacteria < 0.1 cfu/mL Pyrogens (endotoxins) < 0.001 Eu/mL (pyrogen-free) RNases < 0.01 ng/mL (RNase-free) DNases < 4 pg/mL (DNase-free) | |
|
Automated line for preparation and pouring of culture media and solutions
MASTERCLAVE 09 + AUTOMATED FILLER XY500+VC MYLA SYSTEM Bio-Merieux | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 45783,46€ | Institut za javno zdravlje
Vratnica Zoran | 1) MASTERCLAVE 09 Automated system for the preparation of culture media and solutions - Capacity: 1 - 9 liters - sterilization temperature: 95 - 125° - Sterilization time: 1 to 60 minutes - Security cover: cannot be opened at a temperature > 80° C - filling temperature: 25 to 80° C, with an accuracy of +/- 1° C - magnetic stirrer - permanent monitoring of the selected program cycles and temperature, as well as their printing - the possibility of storing 30 fully customizable programs - the possibility of the introduction of new protocols and manual programming - the possibility for connecting system to PC - ticket printer kit 2) APS ONE Automated system for pouring in Petri dishes (Ø90mm and Ø55mm) with stacker Capacity: 560 Petri dish - Filling speed: 700 Petri dish per hour (volume of 14 ml per plate) - "Easy load" peristaltic pump and three silicone tubing systems - Aditional Twin Pump Head peristaltic pump (for addition of blood) - Cooling system - UV lamp active during pouring process - Dispended volume of 1 to 50 ml per Petri dish - Dispended volume of 1 to 1000 ml (for manual filling of containers of various - flasks, test tubes, petri dish ...) - Inkjet printer for Petri dishes 3) XY500 + PM i Automated system for filling of tubes, bottles, etc. - High precision peristaltic pump - accuracy and a repeatability compliant with ISO 7218, ISO 6887-1 & ISO 16189 - Distribution mode: Single-dose, Multi-dose - Adjustable speed - Various diameters of ready-to-use tubing sets - Program management: Cycle, speed, number of doses, delay between each dose - Positioning repeatability > 99% | |
|
MALDI-TOF mass spectrometry system for microbiology
Vitek MS Plus Bio-Merieux | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 186168,11€ | Institut za javno zdravlje
Vratnica Zoran | 1) MALDI-TOF instrument • Capacity: 192 samples per run, 4 slides x 48 tests. Possible of preparing and reading several slides at the same time; - fully automated sample injection, power and targeting laser control software; - linear flow tube length > 1,2 m, - mass resolution > 5000 FWHM-ACTH 18-39 ((M + H) + 2465 Da), - mass range 1 - 500 kDa, - accuracy 30 ppm, - ability to access search engines on the Internet and intranet database for identification of proteins, 2) Preparation station for the preparation and registration of data of the sample, which is via software transmitted directly to the instrument • Computer with barcode scanner, which is connected via USB directly to the relevant hardware; • The possibility of additional preparatory stations at different positions, which are not in the same room with the instrument; • Possibility of integrated sample preparation for MALDI-TOF ID and automated determination of susceptibility testing. 3) The station for collection and compilation of data • Computer with barcode scanner; • Directly connected with the instrument, receives the raw data, processes them, and provides insight into the range (spectrum); • The possibility of a unified analysis of samples for MALDI-TOF ID and automated determination of antimicrobial susceptibility testing. 4) Software • Base IVD with at least 580 clinical types, 13,000 isolates, 25,000 spectrum (average 20 strains / species, average 40 spectrum / type); • The possibility of parallel use of research (Non IVD) database, which should covers at least 1200 species / genera, 9,500 isolates (reference strains), 18,000 spectrum, (average 8 strains / species, average 15spectrum / types); • Creating of superspectra and analysis of dendrograms; • Computer application - middleware, based on web technology, which enables monitoring of related work processes in the laboratory, compatible with laboratory information system, with a central server and multi-user access; • A software connection of existing automated systems in microbiology laboratory; • The possibility of reporting patient results and statistical and epidemiological monitoring of the results. | |
|
HPLC
Nexera XR Shimadzu | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 35500€ | Institut za biologiju mora
Joksimović Danijela | Flow precision: ≤0.06% RSD or ≤0.02 min SD Flow accuracy: ± 1% or better Flow setting range: 0,0001– 5.0000 ml/min in 0.0001 ml/min increments Operating pressure range: 0 – 660 bar Solvent Capacity: quaternary valve system LPGE Number of mixed solvents: 5 Gradient accuracy: maximum +/- 0,5 full scale Seal wash: automatic Bottles for mobile phase, filters, tubing | ||
|
Microwave owen
MULTIWAVE PRO Anton Paar | BIO-ICT | 2 | 2016 | 2016 BIO-ICT 27000€ po komadu | Institut za bioligiju mora (1 komad)
Institut za javno zdravlje (1 komad)
| High microwave power that provides fast vessel heating Unpulsed microwave emission Homogeneous microwave distribution throughout the cavity Maximum safety through pressure-responsive door All stainless-steel construction Fast vessel cooling through powerful air flow system Installed microwave power up to 1.700 watts Microwave cavity entirely made of 18/8 stainless steel housing with multi-layer PTFE plasma coating applied at over 350°C. All hardware protected against acids/organic solvents with polymer coating both on inside and outside surfaces. Micro-switches of which minimum 3 safety interlocks to prevent microwave emission with door open. Exhaust located separate from electronics to prevent corrosion. Graphic display of all, individual sample temperate, and pressures in real time. Patented non-contact IR temperature measurement, (precision +/- 1 C at 300°C) Internal memory for data records and full document – 128 Mbyte of DDR SDRAM (32bit), 1 Gbyte of NAND FLASH (8 Bit) Direct temperature monitor and control up to 310°C in a reference vessel Direct pressure monitor and control up to 115 bar in a reference vessel Touch-screen user interface 9” TFT-LCD screen VGA resolution 800x480 pixel | |
|
Atomic absorption spectrophotometer
AA-7000 Shimadzu | BIO-ICT | 1 | 2016 | 2016 BIO-ICT 22000€ | Institut za biologiju mora
Joksimović Danijela | Wavelength range 185 – 900 nm. Computer controlled wavelength selection; automatic slit 0.2, 0.7, 1.3, 2.0L nm (4-step automatic switching). 6-lamp turret, 2 lamps simultaneously lit (1 for measurement, 1 warming up for next measurement). Automatic lamp position optimisation, Supplied with Air/acetylene burner, Nitrous oxide/acetylene burner Automatic gas control, Automatic fuel gas flow rate setting (0.1 L/min step) Automatic search of optimum gas flow rate • Automatic gas leak check • Automatic Air-N2O switching as C2H2 flow rate increases • Flame monitor • Prevention of wrong burner head use • Gas pressure monitor • Drain tank level monitor • Automatic flame extinction upon power outage or sudden power interruption • Automatic flame extinction via flame vibration sensor • Flashback detection • Internal fan stop sensor Separate ignite and flame off buttons Lamp for Mn, Fe, Pb, Cd, Zn, Ni, Cr, Cu,Co. Supplied with Hollow cathode lamps for As, Hg, Se, Sn. Vapour generation accessory including: • Pump unit • AA hydride module • Cell holder to fit air/acetylene burner • Reagent containers • All tubing, hoses and connectors • Quartz cell Software: • Windows compatible software for data acquisition and processing, and for control of all instrument parameters via a PC • Quantification and Calibration • Data import and export to other software • Possibility to upgrade the system for new instruments | |
|
Analizator električne energije
POWER GUIDE 4400 Dranetz | 1 | 2004 Projekat 6875$ | Laboratorija za EES
| ||||
|
Mjerač otpora izolacije
S1-5005 Megger | 1 | 2004 Projekat 5187€ | Laboratorija za EES
| ||||
|
Generator funkcija
AFG3021 Tektronix | 1 | 2008 | 2008 Tempus projekat 1883€ | Laboratorija za primijenjenu elektroniku
| ||||
|
Analizator spektra
N1996A Agilent | 1 | 2008 | 2008 Tempus projekat 8571€ | Laboratorija za primijenjenu elektroniku
| |||
|
Osciloskop
DPO4104 Tektronix | 1 | 2008 | 2008 Tempus projekat 13920€ | Laboratorija za primijenjenu elektroniku
| ||||
|
Osciloskop
U1640A Agilent | 1 | 2008 | 2008 Tempus projekat 1312€ | Laboratorija za primijenjenu elektroniku
| ||||
|
Osciloskop
MSO6012A Agilent | 1 | 2008 | 2008 Tempus projekat 5019€ | Laboratorija za primijenjenu elektroniku
| ||||
|
Osciloskop
DSO3120A Agilent | 10 | 2008 | 2008 Tempus projekat 1029€ | Laboratorija za primijenjenu elektroniku
| ||||
|
LCR metar
LCR-827 Instek | 1 | 2008 | 2008 Tempus projekat 1696€ | Laboratorija za primijenjenu elektroniku
| |||
|
WARP MIMO kit
WARP MIMO kit | ICT istraživački centar | 2 | 2013 | 2014 ForeMont projekat (FP7) 4915€ | ForeMont research center - Elektrotehnički fakultet
Pejanović-Đurišić Milica | WARP FPGA Board WARP Clock Board Two WARP Radio Boards Two 2.4GHz antennas Two 5GHz antennas | |
|
Open Flow Switch
PRONTO 3290 Pica | ICT istraživački centar | 1 | 2013 | 2014 ForeMont projekat (FP7) 2775€ | ForeMont research center - Elektrotehnički fakultet
Radusinović Igor | Supports OpenFlow 48 10/100/1000BASE-T RJ45 ports 4 10Gbps SFP+ uplink ports 2 10/100/1000BASE-T management ports 1 serial management port - 115.200 Baud rate Forwarding modes: Store-and-forward Bandwidth: 176Gbps Switch latency: less than 40us for 64-bytes frames (nonblocking) Packet buffer embedded in switch chip: 4MB+ | |
|
Workstation
Imac Apple | ICT istraživački centar | 12 | 2013 | 2013 ForeMont projekat (FP7) 2188€ | ForeMont research center - Elektrotehnički fakultet
Pejanović-Đurišić Milica | Processor 3,1GHz Quad-Core Intel i7, 16GB DDR3 (1600MHz) RAM, 1TB HDD, special graphics processor with dedicated memory, 21.5-inch diagonal display with a resolution of minimum 1920×1080, Gigabit Ethernet, 4xUSB 3.0, Thunderbolt port, Bluetooth 4.0, Wireless 802.11n, built-in videoconferencing camera, keyboard, mouse, operating system Mac OS X (Mountain Lion) - preinstalled + Windows 8 Professional 64bit. | ||
|
PreBuilt NetFPGA platform
Accent | ICT istraživački centar | 1 | 2013 | 2014 ForeMont projekat (FP7) 1470€ | ForeMont research center - Elektrotehnički fakultet
Radusinović Igor | AMD Athlon II X2 260 dual core; 2048MB RAM; 250GB SATA HDD; DVD RW; NetFPGA Board; Cube Design case; Dual Port 1Gb/s NIC. | ||
|
Universal Counter
53220A Agilent | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 2060€ | ForeMont research center - Elektrotehnički fakultet
Radonjić Milutin | Frequency range up to 350MHz, 12 digits/s, time interval resolution 100ps, Interface: LAN, USB, GPIB | ||
|
Function Generator
33500B Agilent | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 1570€ | ForeMont research center - Elektrotehnički fakultet
Radonjić Milutin | 1-Channel up to 30 MHz sine, square and pulse signal waveforms, 250 MSa/s, 16-bit sampling rate USB and LAN Interface | ||
|
Server
HP DL360p Hewlett Packard | ICT istraživački centar | 2 | 2013 | 2013 ForeMont projekat (FP7) 4540€ | CIS
| Intel Xeon 6 core processor 2,9GHz, 32GB RAM, 2x2TB HDD, 2x1TB HDD, 4xEthernet port, DVD-ROM, Redundant power supply | ||
|
Rack Cabinet
HP BW904A Hewlett Packard | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 2605€ | CIS
| 42U Standard 19" Rack Cabinet, Cooling system with thermostat, 230 Volt 6 Outlet Power Distribution Unit 48 modules patch panel with Ethernet RJ-45 Cat 6 modules Horizontal Cable Manager 2U | ||
|
Workstation
HPZ620 Hewlett Packard | ICT istraživački centar | 4 | 2013 | 2013 ForeMont projekat (FP7) 3878€ | ForeMont research center - Elektrotehnički fakultet
Radusinović Igor | 2x Intel Xeon 6-core processor at 2,5GHz, 16 GB RAM 1333MHz DDR3 ECC, 2TB HDD, DVD-R/RW, Integrated Ethernet port + AMT, single port Ethernet adapter, dual port Ethernet adapter. HP ProDisplay P221 TFT Monitor HD resolution (1920x1080) LED backlight Keyboard + optical mouse | ||
|
Electric And Magnetic Isotropic Field Analyzer
ESM-100 Maschek | Laboratorija za mjerenje nivoa elektromagnetnih emisija | 1 | 2013 | 2013 ForeMont projekat (FP7) 5000€ | Laboratorija za mjerenje nivoa elektromagnetnih emisija
Radusinović Igor | Frequency range: 5 Hz to 400 kHz Measurement range: 0.1V/m to 100kV/m, 1nT to 20mT Acquisition method: Simultaneous three-axis acquisition Internal data logger up to 24h Control and application software | |
|
Oscilloscope
MSOX 3104A Agilent | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 10735€ | ForeMont research center - Elektrotehnički fakultet
Radonjić Milutin | 1 GHz, 5 GS/s, 4 analog/16 digital channels | ||
|
Optical Time Domain Reflectometer (OTDR)
ST 3300-C Senter | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 2400€ | ForeMont research center - Elektrotehnički fakultet
Veljović Zoran | Wavelengths: 1310nm/1550nm Dynamic range: 30/32dB | ||
|
Fusion Splicer
AV6471 Senter | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 3000€ | ForeMont research center - Elektrotehnički fakultet
Veljović Zoran | Applicable fiber: SMF(ITU-T G.652), MMF(ITU-T G.651), DSF(ITU-T G.653), NZDSF Average splicing loss: 0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS) Align mode: Advanced PAS align mode | ||
|
Multiservice Tester
BL 400A Bluelight | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 5300€ | ForeMont research center - Elektrotehnički fakultet
Radusinović Igor | Multiservice tester enable testing of info-communication infrastructures and services such as: Carrier Ethernet, MPLS L2/L3 VPNs, Multicast and Triple Play services. The tester is able to generate traffic and perform appropriate analysis. Throughput testing, Generate multi stream traffic up to 1Gbit/s line rate on copper and optical multi-ports, Ethernet frames, IP packets layer 1/2/3/4 with multiple modes such as continuous, ramping, burst mode. Packet analysis such as FCS errors, L3/L4 checksum errors, Round Trip Delay (RTD), Packet Arrival Interval (PAI), packet loss, sequence errors. Ports: 2 optical SFP 1000 BASE-SX/LX/ZX and 100 FX 2 copper 10/100/1000 BASE-T Auxiliary RJ45 10/100 Mbit/s Ethernet port Multiple testing capability Ethernet test, VoIP test Fiber channel test (1x, 2x, 4x) Performance measurement (Traffic Generation/Throughput Test) Filtering, IP Tools (Ping, DHCP, Trace Route), Real time in-line monitoring Ethernet OAM/ Loopback (Layer 1/2/3/4), Framed bit error test (BERT) RFC 2544 (Network equipment benchmarking test) Cable faults measurement (copper and optic cables) Remote operation file management, Reporting (ASCII, CSV, and PDF) | ||
|
Signal Analyzer
3252 Aeroflex | ICT istraživački centar | 1 | 2013 | 2014 ForeMont projekat (FP7) 20000€ | ForeMont research center - Elektrotehnički fakultet
Veljović Zoran | Frequency range: 1 kHz - 8 GHz 30 MHz analysis bandwidth, Basic EMI pre compliance measurement capability available, including CISPR 16-1-1 bandwidths, detectors, amplitude correction factor, band preset, tune & listen at marker, and limit lines, LXI class C compliant, USB 2.0, 1000Base-T LAN, GPIB interface Flexible digital modulation analysis measurement application Analog demodulation measurement application | ||
|
Test set
ZT8201, ZT 8651, ZT 8751 ZTEC | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 60000€ | ForeMont research center - Elektrotehnički fakultet
Pejanović-Đurišić Milica | Vector signal generator frequency range: 250MHz – 6GHz RF output: +20 to -80dBm Modulation bandwidth: 500MHz Differential baseband output: DC-200MHz Vector signal analyzer frequency range: 250MHz – 6GHz RF input: +20 to -120dBm Analysis bandwidth 160MHz Differential baseband inputs: DC-300MHz Software for creation and protocol analysis capability For 802.11ac through AC/160MHz Create reference signals: LTE, HSPA+ WiMAX, WLAN, DVB-H, DAB, MATLAB and more Appropriate software for generating 3GPP W-CDMA signals which can be connected to vector signal generator | ||
|
Vektor signal generator
SG 396 Stanford Research Systems | ICT istraživački centar | 1 | 2013 | 2013 ForeMont projekat (FP7) 18000€ | ForeMont research center - Elektrotehnički fakultet
Veljović Zoran | Frequency range: DC to 6.075 GHz Frequency resolution: 1 µHz Analog modulation: AM, FM, ΦM, Pulse, Sweeps Dual baseband generator for I/Q modulation Digital I/O, MIMO fading and RF to RF fading Data types: PRBS, pattern, user Vector Modulation: PSK (including BPSK, QPSK, OQPSK, π/4DQPSK, 8PSK, and 16PSK), QAM (4-256), FSK, CPM (1 – 4 bits), MSK, ASK, VSB Digital filters: Nyquist, root Nyquist, Gaussian, rectangular, linear, sinc, user FIR |
